Small 0.5A Chain actuator for surface mounting suited for natural and smoke ventilation
WMX 504
- Chain actuator for surface mounting
- For comfort ventilation
- For all window types except roof lights
About WMX 504
Main features
-
Natural ventilation
The product is suitable for comfort ventilation to ensure that the building’s users enjoy a comfortable indoor climate
-
±24V Nominal voltage
The product is to be connected to a ±24V control panel
-
MotorLink®
The product communicates with control panels with MotorLink® – an intelligent digital communication from WindowMaster
Product Details
Programmable 24VDC chain actuator - current consumption 0.5A - for surface mounting for comfort ventilation.
Brackets to be ordered seperately.
Specifications
| Installation Type | Surface mounted |
| Window types | Facade windows |
| Chain stroke options | 50 - 250 mm in increments of 10 mm |
| Pressure Force | 150N |
| Traction force | 150N |
| Locking force | 3000 N |
| Operating speed | Programmable from 3mm/s to 10mm/s |
| Sound pressure level | ≤33 dBA (operational speed: 3 mm/s)dBA ≤43 dBA (operational speed: 9.5 mm/s)dBA |
| Power Supply | 24 VDC |
| Current consumption | 0.5 A |
| Nominal Voltage | 24V DC (max. 10% ripple) |
| IP rating | Concealed: IP 32 Surface mounted: IP 20 |
| Size | 29 x 332 x 42 (H x W x D)mm |
| Colour options | Black (RAL 9005) Grey (RAL 9006) White (RAL 9010) |
| Material | Lacquered zinc house with 10mm zinc cromate passivated steel chain |
| To be ordered separately | Brackets and standard extension cables type WLL |
| Networked standby consumption | Please see attachment for networked standby consumption under the MotorController / smoke control panel to which the unit is connected. |
Delivery includes
Actuator with 1.9m connection cable with fast in/fast on connector for WLL cableDownloads
