CompactSmoke™

Tested to EN 12101-10, this is a smoke control system for single zone application or up to 10 zones. It includes the added flexibility of natural ventilation control. Contact us to discuss a smoke control strategy for your building.

Get a system demo

CompactSmoke delivers

  • Icon Building Performance

    Flexible system variants

    CompactSmoke is a solution that comes in 3 variants. 1 variant for a single smoke and comfort zone and 2 variants for up to 10 smoke and comfort zones.

  • Icon Scale

    Scalability

    Several panels can be joined in a master/slave connection so that they can be used in larger buildings.

  • Icon Decrease

    Reduced cabling

    CompactSmoke uses bus technology, reducing the overall cabling for break glass units, smoke detectors, and keypads.

Installation Help

Implementation of one smoke zone - Standard version



How to implement a large smoke area using two panels



Implementation of two smoke zones



Firmware update



Interpret and fix the fault indication through the LED blinking indications



How to retrieve a configuration back-up file



The 3 variants of CompactSmoke

For one zone – WSC 204 / 204BZ / 204KP / 204MH

For the control of ±24V DC actuators, this panel contains a single smoke or comfort ventilation group. This panel can also be combined in master/slave connections.

Offers 1 standard actuator speed.

1 Smoke Zone System Example

For 2 – 10 zones – WSC 310/320 Standard

    • Supplied in two versions: 10A or 20A with up to 2 smoke zones and up to 2 comfort groups.
    • Configuration on DIP switches.
    • The panel can be expanded with a field bus card for comfort ventilation via KNX, BACnet IP, BACnet MS/TP, RS485 or Modbus RTU.
    • Up to three actuator speeds depending on the type of actuator:

      • ±24V DC standard actuator with one speed for SHEV
      • MotorLink® actuator intelligence with three speeds (SHEV / comfort ventilation / intelligent automation)



2 Smoke Zone System Example

For 2 – 10 zones – WSC 310/320 Plus

  • Supplied in two versions, 10A or 20A with up to 10 smoke zones / comfort groups.
  • Includes an easy-to-use 2½” LCD touch screen to configure, commission and maintain.
  • The panel can be expanded with a field bus card for comfort ventilation via KNX, BACnet IP, BACnet MS/TP, RS485 or Modbus RTU.
  • Up to three actuator speeds depending on the type of actuator:

    • ±24V DC standard actuator with one speed for SHEV
    • MotorLink® actuator intelligence with three speeds (SHEV / comfort ventilation / intelligent automation)





2 Smoke Zone System Example

Download Brochure

Would you like to read more about CompactSmoke?

Intelligent control of windows: MotorLink®

MotorLink® is a communication technology that enables 2-way control and feedback between window actuators and the Building Management System via the MotorController. All WindowMaster control systems are MotorLink® capable with many of our actuators. Click below to learn more and see related products.
